SSAW Spiral Submerged Arc Welding Steel Pipe API 5L PSL1 PSL2 SAWH HSAW Pipe

Product Details

Place of Origin: Hunan

Brand Name: Sindara

Certification: ISO 9001, ISO 14001, ISO 45001, CE

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Packaging Details: Bundled/In Bulk, Waterproof Paper Wrapped

Delivery Time: within 10-30 days and depend on your order quantity

Payment Terms: L/C, D/P, T/T, OA

Supply Ability: 1000 Tons Per Day

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                            SSAW Spiral Submerged Arc Welding Steel Pipe, Spiral Submerged Arc Welding Steel Pipe API 5L


Product Name:	Spiral Steel Pipe , SSAW Pipe , SAWH Pipe , Spiral Welded Pipe , Spiral Submerged Arc Welding Pipe , HSAW Pipe	OD:	219.1mm ~ 3500mm
WT:	6mm ~ 25mm (Up To 1'')	LENGTH:	6mtr ~ 18mtr
Standard & Grade:	ASTM A53, Grade A/B/C,API 5L,PSL1,PSL2,GR.B/X42-X80,ASTM A795,ASTM A135,ASTM A252,GR.1/2/3,AWWA C200	Ends:	Plain Ends, Beveled Ends,Threaded Ends
Usage:	Used For Fluids Transmission, Structural Support In Industrial Construction,Equipment Fabrication

Product Name:	Spiral Steel Pipe , SSAW Pipe , SAWH Pipe , Spiral Welded Pipe , Spiral Submerged Arc Welding Pipe , HSAW Pipe
OD:	219.1mm ~ 3500mm
WT:	6mm ~ 25mm (Up To 1'')
LENGTH:	6mtr ~ 18mtr
Standard & Grade:	ASTM A53, Grade A/B/C,API 5L,PSL1,PSL2,GR.B/X42-X80,ASTM A795,ASTM A135,ASTM A252,GR.1/2/3,AWWA C200
Ends:	Plain Ends, Beveled Ends,Threaded Ends
Usage:	Used For Fluids Transmission, Structural Support In Industrial Construction,Equipment Fabrication

SSAW Spiral Submerged Arc Welding Steel Pipe API 5L PSL1 PSL2 SAWH HSAW Pipe

Spiral Steel Pipe ( SSAW Steel Pipe / SAWH PiPE )

Short Description:

Keywords: Spiral Steel Pipe , SSAW Pipe , SAWH Pipe , Spiral Welded Pipe , Spiral Submerged Arc Welding Pipe , HSAW Pipe
Size: OD: 219.1mm ~ 3500mm ; WT: 6mm ~ 25mm ( Up to 1'' ) ; LENGTH: 6mtr ~ 18mtr, SRL, DRL
Standard & Grade:ASTM A53 , Grade A/B/C , API 5L ,PSL1 ,PSL2 ,GR.B/X42-X80 , ASTM A795 , ASTM A135 , ASTM A252 , GR.1/2/3
Ends: Plain Ends , Beveled Ends ,Threaded Ends
Delivery: Within 10-30 days and depends on your order quantity
Payment: L/C, D/P, T/T, OA
Packing:Bundled/In Bulk , Waterproof Paper Wrapped
Usage:Used for Fluids Transmission , Structural Support in Industrial Construction , Equipment Fabrication

SSAW Steel Pipe

Spiral welded pipe ( SSAW pipe , also called HSAW pipe ). The pipe is formed by spiral submerged arc welding technology. Spiral welded pipes are formed using narrower plates or hot rolled coils , which lowers their production costs significantly. The welding line shape like a helix. The spiral welding process permits the production of large-diameter pipes suitable for transporting large volumes of oil and gas. Some SSAW pipes are historically limited to low pressure applications.

Product:	Spiral Steel Pipe , SSAW Pipe , SAWH Pipe , Spiral Welded Pipe , Spiral Submerged Arc Welding Pipe , HSAW Pipe
Application:	Used for Oil / Gas / Water transmission , Construction & Structure Parts
Size:	OD: 219.1mm-3500mm
	WT: 6-25mm
	LENGTH: 5.8/6/11.8/12m
Pipe Standard:	API 5L PSL1/PSL2 Gr.A , Gr.B , X42 , X46 , X52 , X56 , X60 , X65 , X70
	ASTM A53 / A252 / A500
	EN10219 / EN10208 / EN10297
	JIS G3457

Product Specification and Size

Product Name	Executive Standard	Dimension (mm)	Steel Code / Steel Grade
Casting	API 5CT	Ø48.3~273 x WT2.77~11.43	J55 , K55 , N80 , L80
Tubing	API 5CT	Ø48.3~273 x WT2.77~11.43	J55 , K55 , N80 , L80 , H40
Line Pipes	API 5L	Ø60.3~273.1 x WT2.77~12.7	A25 , A , B , X42 , X46 , X52 , X56 , X60 , X65 , X70 , X80
Electric-Resistance-Welded Steel Pipes	ASTM A135	Ø42.2~114.3 x WT2.11~2.63	A
ERW and Hot-dip Galvanized Steel Pipes	ASTM A53	Ø21.3~273 x WT2.11~12.7	A , B
Pipes for Piling Usage	ASTM A252	Ø219.1~508 x WT3.6~12.7	Gr.2 , Gr.3
Tubes for General Structural Purpose	ASTM A500	Ø21.3~273 x WT2.11~12.7	Gr.2 , Gr.3
Square Pipes for General Structural Purpose	ASTM A500	25 x 25~160 x 160 x WT1.2~8.0	Carbon Steel
Threaded Steel Pipes	DIN 2440	Ø21~164 x WT2.65~4.85	Carbon Steel
Screwed and Socketed Steel Tubes	BS 1387	Ø21.4~113.9 x WT2~3.6	Carbon Steel
Scaffolding Pipes	EN 39	Ø48.3 x WT3.2~4	Carbon Steel
Carbon Steel Tubes for General Structure Purpose	JIS G3444	Ø21.7~216.3 x WT2.0~6.0	Carbon Steel
Carbon Steel Tubes for Machine Structure Purpose	JIS G3445	Ø15~76 x WT0.7~3.0	STKM11A , STKM13A
Carbon Steel Pipes for Ordinary Piping	JIS G3452	Ø21.9~216.3 x WT2.8~5.8	Carbon Steel
Carbon Steel Pipes for Pressure Service	JIS G3454	Ø21.7~216.3 x WT2.8~7.1	Carbon Steel
Carbon Steel Rigid Steel Conduits	JIS G8305	Ø21~113.4 x WT1.2~3.5	G16~G104 , C19~C75 , E19~E75
Carbon Steel Rectangular Pipes for General Structure	JIS G3466	16 x 16~150 x 150 x WT0.7~6	Carbon Steel

Dimension of SSAW Steel Pipe

SSAW Spiral Submerged Arc Welding Steel Pipe API 5L PSL1 PSL2 SAWH HSAW Pipe 0

Application of Welded Steel Pipe

Welded steel pipes are commonly used in a wide range of applications and industries , including:

Water and wastewater transportation: Welded steel pipes are used to carry water , sewage , and other fluids in municipal and industrial plumbing systems.

Oil and gas pipelines: Welded steel pipes are utilized in the construction of pipelines for the transportation of oil , natural gas , and other hydrocarbons.

Structural applications: They are used in the construction of buildings, bridges, and other structures as structural support elements.

Automotive and transportation: Welded steel pipes are used in the manufacturing of automobile exhaust systems and chassis components.

Manufacturing and industrial processes: They are used in various manufacturing and industrial applications, including conveying materials and gases within factories.

Agriculture: Welded steel pipes are used for irrigation systems, drainage, and other agricultural applications.

Manufacturing Process

SSAW Spiral Submerged Arc Welding Steel Pipe API 5L PSL1 PSL2 SAWH HSAW Pipe 1
