Cold Drawn / Hot Rolled ERW Steel Pipe Electric Resistance Welding Pipe

Large Image : Cold Drawn / Hot Rolled ERW Steel Pipe Electric Resistance Welding Pipe

Product Details:

Place of Origin:	Hunan
Brand Name:	Sindara
Certification:	ISO 9001, ISO 14001, ISO 45001, CE

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Price:	Pirce is negotiable
Packaging Details:	Bundled/In Bulk, Plastic Caps Plugged, Waterproof Paper Wrapped
Delivery Time:	within 10-30 days and depend on your order quantity
Payment Terms:	L/C, T/T, OA, D/P
Supply Ability:	500 tons per day

Contact Now

Cold Drawn / Hot Rolled ERW Steel Pipe Electric Resistance Welding Pipe

Description

Outer Diameter ::	21.3mm ~ 660mm	Wall Thickness ::	1-20mm (SCH40, SCH80, SCH160, SCHXS, SCHXXS, All Schedules)
Length ::	1-12m Or As Per Customer Requirement	Standard ::	ASTM 5L, ASTM A53, ASTM A178, ASTM A500/501, ASTM A691, ASTM A252, ASTM A672, EN 10217
Ends ::	Plain End / Beveled End / Threaded	Surface Treatment ::	Bare, Painting Black, Varnished, Galvanized, Anti-corrosion 3PE PP/EP/FBE Coating
Process ::	Cold Drawn / Hot Rolled	Application ::	Used For Oil / Gas / Water Transmission , Machinery Manufacturing
Highlight:	Hot Rolled ERW Steel Pipe , Cold Drawn ERW Steel Pipe , ERW Electric Resistance Welding Pipe

Description

Product Name: ERW Steel Pipe , HFW Pipe , Electric Resistance welding Pipe

Outer Diameter: 1/2"-28"

Wall Thickness: 1.65-20mm (All Schedules)

Length: 1-12m or As Customer Requirement

Standard: ASTM 5L, ASTM A53, ASTM A178, ASTM A500/501, ASTM A691, ASTM A252, ASTM A672, EN 10217

Material Grade (EN):

API 5L: PSL1/PSL2 Gr.A, Gr.B, X42, X46, X52, X56, X60, X65, X70

ASTM A53: GR.A, GR.B

EN: S275, S275JR, S355JRH, S355J2H

Ends: Plain End / Beveled End / Threaded

Surface Treatment: Bare, Painting Black, Varnished, Galvanized, Anti-corrosion 3PE PP/EP/FBE coating etc.

Process: Cold Drawn / Hot Rolled

Test: Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Bending Test, Hardness Test, Impact Test), Exterior Size Inspection, Hydrostatic Test, NDT TEST ( ET TEST, RT TEST, UT TEST)

Specification:

INCH	OD (MM)	Strandard Wall Thickness
INCH	OD (MM)	SCH 10WT (mm)	SCH 20WT (mm)	SCH 40WT (mm)	SCH 60WT (mm)	SCH 80WT (mm)	SCH 100WT (mm)	SCH 160WT (mm)	XXS (mm)
1/4”	13.7			2.24		3.02
3/8”	17.1			2.31		3.2
1/2”	21.3	2.11		2.77		3.73		4.78	7.47
3/4"	26.7	2.11		2.87		3.91		5.56	7.82
1"	33.4	2.77		3.38		4.55		6.35	9.09
1-1/4"	42.2	2.77		3.56		4.85		6.35	9.7
1-1/2"	48.3	2.77		3.68		5.08		7.14	10.15
2"	60.3	2.77		3.91		5.54		8.74	11.07
2-1/2"	73	3.05		5.16		7.01		9.53	14.02
3"	88.9	3.05		5.49		7.62		11.13	15.24
3-1/2"	101.6	3.05		5.74		8.08
4"	114.3	3.05	4.5	6.02		8.56		13.49	17.12
5"	141.3	3.4		6.55		9.53		15.88	19.05
6"	168.3	3.4		7.11		10.97		18.26	21.95
8"	219.1	3.76	6.35	8.18	10.31	12.7	15.09	23.01	22.23
10"	273	4.19	6.35	9.27	12.7	15.09	18.26	28.58	25.4
12"	323.8	4.57	6.35	10.31	14.27	17.48	21.44	33.32	25.4
14"	355	6.35	7.92	11.13	15.09	19.05	23.83	36.71
16"	406	6.35	7.92	12.7	16.66	21.44	26.19	40.49
18"	457	6.35	7.92	14.27	19.05	23.83	29.36	46.24
20"	508	6.35	9.53	15.09	20.62	26.19	32.54	50.01
22"	559	6.35	9.53		22.23	28.58	34.93	54.98
24"	610	6.35	9.53	17.48	24.61	30.96	38.89	59.54
26"	660	7.92	12.7
28"	711	7.92	12.7
30"	762	7.92	12.7
32"	813	7.92	12.7	17.48
34"	863	7.92	12.7	17.48
36"	914	7.92	12.7	19.05
38"	965
40"	1016
42"	1066
44"	1117
46"	1168
48"	1219

Chemical Analysis and Mechanical Properties

Standard	Class	Grade	Chemical Analysis(%)				Mechanical Properties(min)(Mpa)
Standard	Class	Grade	C	Mn	P	S	Tensile Strength	Yield Strength
API 5L	PSL1	B	0.26	1.20	0.030	0.030	414	241
		X42	0.26	1.30	0.030	0.030	414	290
		X46	0.26	1.40	0.030	0.030	434	317
		X52	0.26	1.40	0.030	0.030	455	359
		X56	0.26	1.40	0.030	0.030	490	386
		X60	0.26	1.40	0.030	0.030	517	414
		X65	0.26	1.45	0.030	0.030	531	448
		X70	0.26	1.65	0.030	0.030	565	483
	PSL2	B	0.22	1.20	0.025	0.015	414	241
		X42	0.22	1.30	0.025	0.015	414	290
		X46	0.22	1.40	0.025	0.015	434	317
		X52	0.22	1.40	0.025	0.015	455	359
		X56	0.22	1.40	0.025	0.015	490	386
		X60	0.22	1.40	0.025	0.015	517	414
		X65	0.22	1.45	0.025	0.015	531	448
		X70	0.22	1.65	0.025	0.015	565	483
		X80	0.22	1.85	0.025	0.015	621	552

Process

Cold Drawn / Hot Rolled ERW Steel Pipe Electric Resistance Welding Pipe 0

Packing

1. Plastic caps plugged at the two sides of pipe ends
2. Should be avoided by the steel strapping and transport damage
3. Bundled signs should be uniform and consistent
4. The same bundle(batch) of steel pipe should be came from the same furnace.
5. The steel pipe has the same furnace number, the same steel grade, the same specifications.

Tag:

Electric Resistance Welding Pipe,

Welded Carbon Steel Pipe,

ERW Steel Tube
