epoxy powder coating 3PP Three-layer structure polyolefin epoxy powder coating

Name: epoxy powder coating 3PP Three-layer structure polyolefin epoxy powder coating
Brand: Sindara Steel Co.,Ltd
SKU: (Standard ISO 21809-1:2018)
Price: 2,550.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Sindara steel

Certification: ISO 9001, ISO 14001, ISO 45001, CE

Model Number: (Standard ISO 21809-1:2018)

Payment & Shipping Terms

Minimum Order Quantity: 1TON

Price: 100USD-5000USD

Packaging Details: Carton outer packing, lined with polyethylene bag

Delivery Time: 10-30DAYS

Payment Terms: L/C, T/T

Supply Ability: 1000000

Get Best Price

Product Details

Product Description

Highlight:
                                    3PP epoxy powder coating, Three-layer structure epoxy powder coating, Polyolefin epoxy powder coating


epoxy powder coating 3PP Three-layer structure polyolefin epoxy powder coating

Description

3LPP (Standard ISO 21809-1:2018)

The epoxy powder coating is the implementation of ISO 21809-1:2018 standard, which

is the bottom design of the three-layer structure of polypropylene in buried steel-made pipe, using appropriate epoxy resin, curing agent, pigment, filler, etc., and can form a composite anti-corrosion system with excellent performance with intermediate layer adhesive and outer polypropylene.

1. Application scope and characteristics

●External anti-corrosion of steel pipe and pipe fittings.

●Compared with other forms of anti-corrosion, it has the characteristics of good adhesion, strong cathode disbondment, and collision and damage prevention.

●It has the characteristics of mature process, wide application range, long anti-corrosion life, and wide operating temperature range (-20℃ ~100℃).

2. Method and dosage

1 Coating method: Electrostatic spraying.

2 Theoretical dosage: 150g/M2/100μm.

3 Surface treatment: Sandblasting or Pelblasting.

4 Curing instructions: Apply the powder coating on the surface of 200~220℃. When the powder coating forms a gelatinized state, the middle adhesive layer is squeezed and wound, so that the two layers are integrated into one, and then wrap the polypropylene layer, and finally form a complete three-layer coating structure.

3.Production Department

epoxy powder coating 3PP Three-layer structure polyolefin epoxy powder coating 0

4. Paking
